NEC UM361X – 3600 Lumens, XGA, Ultra Short & Interactive Projector

NEC UM361W, 3600 Lumens XGA, Ultrashort Through Projector with Wall Bracket and Optional Interactive Kit and Optional Wireless Module is for Schools University and Offices. – 3 years warranty from NEC

$985,55

Guaranteed Safe Checkout

Features & Compatibility

NEC’s UM361X is a 3600-lumen ultra short throw projector that packs a multitude of features while delivering an extremely short throw distance for education and corporate applications. A complete interactive projector solution can be created using the optional NP04Wi interactive system (dual pens) with auto calibration. With its ability to be mounted to the wall directly above the screen on which it projects, this model helps eliminate the shadows and glare typically found with standard projection systems. The UM361X includes a powerful 20W speaker, closed captioning and RJ-45 for remote management over a network, and its input panel includes dual HDMI, VGA and a microphone input to amplify the presenter’s voice.

  • Ultra short throw lens (0.36:1 throw ratio) helps eliminate shadows on the screen along with projected light in the presenter’s eyes created by traditional front projection systems
  • Comprehensive input/output panel, including dual HDMI, VGA and a microphone input
  • ECO Mode™ technology helps extend lamp life and lowers power consumption
  • Horizontal & Vertical Keystone adjustment or Cornerstone Correction ensures the image will fill the screen every time
  • Remote monitoring and control of projector over network saves IT employee time and reduces costs related to projector operation
  • Optional interactive system (dual pens) with auto calibration allows for annotation and collaboration on a whiteboard locally or via web meetings
  • Available as a bundle with one widescreen ultra short throw projector and NP04WK1 wall mount kit (NP-UM361X-WK)
  • Available as a bundle with one widescreen ultra short throw projector, NP04Wi interactive module and dual stylus pens, and NP04WK1 wall mount kit (NP-UM361Xi-WK)

  • NEC UM351W Projector is Ultra short throw lens (0.36:1 throw ratio) helps eliminate shadows on the screen along with projected light in the presenter’s eyes created by traditional front projection systems
  • Comprehensive input/output panel, including dual HDMI, VGA and a microphone input
  • ECO Mode™ technology helps extend lamp life and lowers power consumption
  • Horizontal & Vertical Keystone adjustment or Cornerstone Correction ensures the image will fill the screen every time
  • Remote monitoring and control of projector over network saves IT employee time and reduces costs related to projector operation
  • Optional interactive system (dual pens) with auto calibration allows for annotation and collaboration on a whiteboard locally or via web meetings
  • Available as a bundle with one widescreen ultra short throw projector and NP04WK1 wall mount kit (NP-UM351W-WK)
  • Available as a bundle with one widescreen ultra short throw projector, NP04Wi interactive module and dual stylus pens, and NP04WK1 wall mount kit (NP-UM351Wi-WK)
  • Available as a bundle with projector, interactive module, touch module and custom wall mount (NP-UM351WI-TM)

NEC UM361X Projector Specifications

Display

Aspect Ratio 4×3 Native Resolution XGA 1024×768
Maximum Resolution WUXGA 1920 x 1200 Contrast Ratio (typical) 4000:1

Synchronization Range

Horizontal (Analog/Digital) 15-100 kHz Vertical 50-120 Hz

Signal Compatibility/Connectivity

Supported Video Standards NTSC, NTSC4.43, PAL, PAL-M, PAL-N, PAL 60, SECAM SD/HD Video Signal Compatibility 480i, 480p, 576i, 576p, 720p, 1080i, 1080p
PC Signal Compatibility VGA, SVGA, XGA, WXGA, WXGA+, SXGA, SXGA+, UXGA Macintosh Signal Compatibility Yes
Microphone 1/8 in. stereo Sync Compatibility Separate Sync / Composite Sync / Sync on G
External Control RS-232, IR, Wired LAN, DDC/CI, USB, Wireless LAN (optional) Input Terminals

RGB1(analog):
VGA 15-pin D-sub, Component video using ADP-CV 1E adapter
RGB2(digital):
HDMI/HML w/HDCP
RGB3(digital):
HDMI w/HDCP
RGB4(digital):
USB A Type
Video 1:
RCA
Audio 1:
1/8 in. stereo
Audio 2:
L/R RCA (shared by video sources)
Output Terminals

Audioout:
Yes (variable)
Monitor Out:
VGA 15-pin D-sub

Power Consumption (typical)

On 337W / 221W / 8W / 0.2W Input Current 3.8A/1.6A
Power Requirements 100-240V AC, 50/60 Hz

Physical Specifications

Dimensions (WxHxD)

Product:
16.9 x 23.3 x 4.4 in. / 429 x 592 x 112mm
Weight

Net Weight:
12.4 lbs. / 5.6 kg

Environmental Conditions

Operating Temperature 41-104°F / 5-40°C Storage -4-122°F / -20-50°C

Limited Warranty (parts & labor)

Registered owners receive a 3 year parts and labor warranty including InstaCare next business day exchange. The lamp is covered for one year or 1,000 hours, whichever comes first.

Additional information

Weight 8 kg
Dimensions 50 × 50 × 50 cm
brand

NEC

Lumens

3000-5000 Lumens

Resolution

WXGA
