DISPLAY SIZE (IN.)
75
RESOLUTION
3840 x 2160
STATIC CONTRAST RATIO
1,200:1
LIGHT SOURCE
LED
DISPLAY
DISPLAY SIZE (IN.)
55
VIEWABLE AREA (IN.)
54.6
LIGHT SOURCE
LED
RESOLUTION
3840 x 2160
ASPECT RATIO
16:9
STATIC CONTRAST RATIO
1,200:1
BACKLIGHT LIFE (HOURS)
50,000
BRIGHTNESS
350 cd/m2
RESPONSE TIME (TYPICAL GTG)
8ms
VIEWING ANGLES
178º horizontal, 178º vertical
PANEL SURFACE
Anti-glare 7H tempered glass
NETWORKING
ETHERNET LAN
10/100/1000 Mbps
EMBEDDED PLAYER
ANDROID VERSION
7.0
GPU
ARM Mali450 Quad Core
CPU
ARM Quad Core Cortex A73
CPU PROCESSOR SPEED
1.2GHz
MEMORY
2GB
STORAGE
16GB
INTERFACE
OSD / Remote Control / Annotation overlay
AUDIO
INTERNAL SPEAKERS
10W (x2)
WOOFER
15W (x1)
CONNECTOR
HDMI 2.0
3
HDMI OUT
1
VGA
1
COMPOSITE RCA
1
3.5MM AUDIO IN
1
3.5MM AUDIO OUT
1
SPDIF AUDIO OUT
1
USB 3.0
2
USB 2.0
4
USB B TOUCH PORT
2
RS232
1
ETHERNET LAN (RJ45)
1
WIFI MODULE SLOT
1
POWER
VOLTAGE
100-240 VAC
CONSUMPTION (TYPICAL)
350W
STAND-BY
<0.5W
CONTROLS
ON SCREEN DISPLAY
Input, Volume, Backlight, Audio, Screen, Display, Adjust
REMOTE CONTROL
Volume, Channel, Source, Mute, Back, Input, Menu
OPERATING CONDITIONS
TEMPERATURE
32-104º F (0 – 40º C)
HUMIDITY (NON-CONDENSING)
10-90%
TOUCH
TOUCH TECHNOLOGY
Infrared
TOUCH POINTS
20-Point Touch
TIP DETECTION
Dual tips, 3mm and 8mm
WEIGHT (METRIC)
NET (KG)
31.0
GROSS (KG)
39.0
WEIGHT (IMPERIAL)
NET (LBS)
68.3
GROSS (LBS)
86.0
DIMENSIONS (METRIC) (WXHXD)
PACKAGING (MM)
1428.0 x 878.0 x 220.0
PHYSICAL (MM)
1268.0 x 773.0 x 85.0
DIMENSIONS (IMPERIAL) (WXHXD)
PACKAGING (IN.)
56.2 x 34.6 x 8.7
PHYSICAL (IN.)
49.9 x 30.4 x 3.3
